UF0655 course graphical representation

Topographic surveys are intended to determine the main physical characteristics of the land, as well as the position on the surface of the Earth. The data obtained in a topographic survey are the basis for the graphic representation or elaboration of the map of the area we study. Therefore, it is very important to perform field and cabinet work for lifting land and constructions, using direct and indirect methods, and performing project rethinks, following the criteria established in quality and safety. This course provides the necessary knowledge and skills for cabinet work for uprisings and their graphic representation.

The objectives to be achieved with the realization of this graphic representation course of elements are the following: - Perform the digital modeling of the land based on field work data, extracting and interpreting the information obtained and using specific computer applications. - Analyze the different types of construction representations, describing the complementary information they must incorporate. - Produce the graphic representation of land and constructions from the numerical models, sketches or planes defined after the field work, using computing applications of assisted design, applying coding, scales and established formats, and organizing its file.

After doing this online course you can work in project and execution areas. Draw yourself professionally as an autonomous or wage worker in small, medium and large companies in departments in charge of the graphic representation of elements.

This formation conforms to the training itinerary of the Formative Unit UF0655 Graphical representation of uprisings. Certifying having overcome the different competition units included. And is aimed at the accreditation of the professional competences acquired through work experience and non -formal training. Route for which you will choose to obtain the corresponding certificate of professionalism, through the respective calls that are publishing the different autonomous communities. As well as the Ministry of Labor (Royal Decree 659/2023, of July 18, which develops the management of the professional training system and establishes a permanent procedure for the accreditation of professional competences acquired by work experience or non -formal training).

This graphic representation course of elements is aimed at those professionals in the building and civil works. Specifically within the professional area of structures. And in general it addresses all those interested in acquiring knowledge related to the cabinet work for uprisings and their graphic representation.

This training is not included in the scope of official regulated training (Infant Education, Primary Education, Secondary Education, Official Professional Training FP, Baccalaureate, University Degree, Official University Master and PhD). It is therefore a complementary and/or specialization training, aimed at acquiring certain skills, skills or aptitudes of a professional nature, being able to be barely as merit in workbags and/or opposition competitions, always within the complementary training section and/or continuous training being always essential to review the specific requirements of the public labor stock of the public labor stock market.
